HK-YLP-30W Aluminum Window Fiber Laser Marking Machine

Fiber Laser Marking | 30W Power | Marking Speed 0-12000mm/s | Ideal for Window & Door Industry

HK-YLP-30W Aluminum Window Laser Marking Machine Laser Marking Detail Laser Marking Application Laser Marking System
Thumbnail 1 Thumbnail 2 Thumbnail 3 Thumbnail 4
128 Reviews

HK-YLP-30W Aluminum Window Fiber Laser Marking Machine

The HK-YLP-30W fiber laser marking machine is the most advanced third-generation laser marking system. It features high photoelectric conversion efficiency (up to 70%) and uses a high-speed scanning galvanometer system for marking. Air-cooled design, compact size, and excellent output beam quality.

Model: HK-YLP-30W

Laser Power: 30W

Working Medium: Fiber

Laser Wavelength: 1064nm

Marking Area: 0-110mm

Marking Speed: 0-12000mm/s

Engraving Depth: 0.01mm-0.5mm (Adjustable)

Engraving Width: 0.05mm-0.20mm

Repeatability: ≤0.002mm

Laser Frequency: 20KHZ-200KHZ Continuously Adjustable

Cooling Method: Air Cooling

Laser Source Lifespan: ≤100,000 Hours

Applicable Materials: Aluminum alloy windows, screen windows, aluminum doors & windows, window hardware accessories, thermal break strips, hollow aluminum spacers, window drainage covers, edge sealing strips, aluminum veneer, etc.

Availability: In Stock - Ready to Ship

Get a Free Quote Brochure
Share

HK-YLP-30W Aluminum Window Fiber Laser Marking Machine - Product Description

Key Features
  1. The HK-YLP-30W fiber laser marking machine is the most advanced third-generation laser marking system. It features high photoelectric conversion efficiency (up to 70%) and uses a high-speed scanning galvanometer system for marking.
  2. Air-cooled design with compact size and excellent output beam quality (M2 close to 1, beam divergence angle of 0.24mard). High pulse repetition frequency, stable power, single pulse energy fluctuation less than 1%, enabling high-speed laser marking with precise control of spot size, depth, and shape.
  3. High reliability, capable of engraving metal materials and some non-metal materials, with ultra-long operating life and energy efficiency.
  4. Highly integrated, compact machine structure with low energy consumption.
  5. Fast marking speed, marking efficiency is 5 times that of traditional products.
  6. Long lifespan, maintenance-free, low operating cost. Lifespan can reach 10 times that of traditional products.

Technical Specifications

Parameter Specification
Working Medium Fiber
Pumping Method Fiber
Laser Power 30W
Laser Wavelength 1064nm
Laser Frequency 20KHZ-200KHZ Continuously Adjustable
Repeatability ≤0.002mm
Marking Area 0-110mm
Cooling Method Air Cooling
Marking Speed 0-12000mm/s
Engraving Depth 0.01mm-0.5mm (Adjustable)
Engraving Width 0.05mm-0.20mm
Fiber Laser Source Lifespan ≤100,000 Hours

Applicable Materials

Aluminum alloy windows, screen windows, aluminum doors & windows, window hardware accessories, thermal break strips, hollow aluminum spacers, window drainage covers, edge sealing strips, aluminum veneer, etc.
